| screw-in cartridge valves | sv5-8-0-0-24dgs | ||
| Baugröße | -8 : 8 size, max flow - 23 l/min [6 gpm] | ||
| style | -0 : 2-way 2-position normally open (restricted reverse flow when de-energized) | ||
| filter | none | ||
| valve housing port | -0 : cartridge only | ||
| voltage type protection | d : dc / with no protection | ||
| lead length | none | ||
| coil special feature | none |
| Baureihe | sv5 : sv5 - solenoid valve - 210 bar [3000 lbf/in2] | ||
| Dichtung | buna-n | ||
| Handhilfsbetätigung | none | ||
| valve housing material | none | ||
| voltage rating | -24 : 24 volt | ||
| connector type | g : din 43650-a | ||
| coil series | s : size 8 - 210 bar [3000 1bf/in2] | ||
| valve special features | none |
