| regulation range min. | 0 bar | ||
| actual output value | 0 ... 20 ma | ||
| Electrical connection | via signal connection | ||
| permissible ripple | 5% | ||
| Hysteresis | < 0,06 bar | ||
| control | analog | ||
| Medium | compressed air | ||
| compressed air connection output | g 1/4 | ||
| max. ambient temperature | 70 °c | ||
| working pressure max | 11 bar | ||
| certificates | ce declaration of conformity |
| nominal input value | 0 ... 20 ma | ||
| signal connection | 5-pin | ||
| Protection class | ip65 | ||
| mounting orientation | α = 0-90° β = 0-90° | ||
| dc operating voltage | 24 v | ||
| nominal flow qn | 1000 l/min | ||
| compressed air connection, exhaust | g 1/4 | ||
| compressed air connection input | g 1/4 | ||
| min. ambient temperature | 0 °c | ||
| working pressure min. | 0 bar | ||
| Type | poppet valve |
