| port d | nw 7,4 | ||
| compressed air connection type | collar | ||
| nominal flow qn | 1800 l/min | ||
| working pressure max | 16 bar | ||
| max. ambient temperature | 100 °c | ||
| max. medium temperature | 100 °c | ||
| delivery unit | 1 piece | ||
| Housing Material | aluminum | ||
| Material connector | steel |
| Port G | Ø 10 | ||
| nominal width nw | 7.4 mm | ||
| working pressure min. | 0 bar | ||
| min. ambient temperature | -20 °c | ||
| min. medium temperature | -20 °c | ||
| Medium | neutral gases, compressed air | ||
| weight per piece | 0.124 kg | ||
| seal material | caoutchouc/butadiene caoutchouc |
