| direct mounting for series | pra, ssi, gsu, rtc, ckp, gpc, msc, msn, rcm, cvi | ||
| slot width | 4 mm c-slot | ||
| type of contact | reed | ||
| certificates | ul (underwriters laboratories), culus, rohs | ||
| min. ambient temperature | -30 °c | ||
| voltage drop u at imax | ≤ 0,5 v | ||
| ac switching current, max. | 0.13 a | ||
| switching logic | no (make contact) | ||
| led status display | yellow | ||
| electrical connection 2, number of poles | 3-pin | ||
| operating voltage dc, max. | 30 v dc | ||
| Shock resistance | 30 g / 11 ms | ||
| cable length l | 3 m |
| indirect mounting for series | mni, csl-rd, icm | ||
| cable | with cable | ||
| switching capacity | 3 w / 3 va | ||
| Protection class | ip65, ip67 | ||
| max. ambient temperature | 80 °c | ||
| dc switching current, max. | 0.13 a | ||
| switching point precision | ±0,1 mt | ||
| Display | led | ||
| electrical connection 2, type | open cable ends | ||
| operating voltage dc, min. | 5 v dc | ||
| short circuit resistance | protected against polarity reversal | ||
| Vibration resistance | 10 - 55 hz, 1 mm |
