| Maximum operating current per contact | 8 | A | |
| Operating voltage (min ... max) | 10 V DC ... 30 V DC | ||
| Cable bushing, housing | 1 seal with bore 2x 5.5 mm, 1x 3.5 mm, 1 seal, adaptable, max. Ø 14 mm | ||
| Connection, flanged socket | Soldered connection, ≤ 1 mm | ||
| Cable diameter (min ... max) | 10 mm ... 14 mm |
| Pin number | 16 | ||
| Plug cycles | > 50 | ||
| Cable bushing, plug | Bolting with pull relief | ||
| Connection, plug | Soldered connection, ≤ 1 mm | ||
| Permissible ambient temperature (min ... max) | -20 °C ... +125 °C |
