| C | 6,560 | N | |
| ML | 249 | Nm | |
| My max | 80 | Nm | |
| Fy max | 2,100 | N | |
| Lmax | 2,500 | mm | |
| vmax (Speeds of up to 5 m/s possible. Service life is limited by the heightened wear of the plastic parts. ) | 3 | m/s |
| Mt | 236 | Nm | |
| Mx max | 76 | Nm | |
| Mz max | 80 | Nm | |
| Fz max | 2,100 | N | |
| amax (For linear motion slides without drive SGO/SOO, unlike the SGK/SOK, there is no ball screw assembly as a limiting factor for acceleration. ) | 150 | m/s² |
