NORGREN P68F-8GH-PPA olympian plus soft start dump valve

Name: P68F-8GH-PPA NORGREN
Brand: NORGREN
SKU: 790112-en-eur
Price: 1259.22 EUR
Availability: SoldOut

1,259.22 € ~~1,794.39 €~~ -29%

Limited stock only available on quotation

Specifications

Actuation Type	solenoid pilot / spring return
max. pressure	3 ... 10 bar

supply voltage	24vdc, 4.5w

actuation		solenoid pilot / spring return
body		zinc alloy
connector plug		3pin plug with cable gland
elastomers		synthetic material
flow flow dm3sec		147 dm3/sec
gauge port		rc1/8
Manual override		button (shrouded)
maximum inlet pressure pressure bar		10 bar
operating pressure pressure bar min to max range		3 ... 10 bar
operating temperature f temperature fahrenheit min to max range		-4 ... 149 °f
operation		3/2
Port size		g1
range		p68f
voltage		24vdc, 4.5w

air pilot ports		g1/4
bonnet		zinc alloy
data performance shelf life		3 years
exhaust port		g1
flow flow dm3secbar		147 dm3/(s.bar) dm3/sec
inner parts		steel
maximum inlet pressure imperial pressure psi		145 psig
Medium		compressed air
operating pressure psi pressure psi min to max range		44 ... 145 psi
operating temperature temperature celsius min to max range		-20 ... 50 °c
operator		32mm solenoid with manual lockout
product style		plug-in
Series		olympian plus
