| Permissible axial displacement | s | max.2.9 | |
| Raceway diameter of outer ring | E | 177.50 | mm |
| Width | B | 45 | mm |
| Bore diameter | d | 95 | mm |
| chamfer dimension | rmin | min.3 | |
| Shoulder diameter of inner ring | d2 | ≈132 | |
| Outside diameter | d2 | 200 | mm |
| Manufacturer | Part Number |
|---|---|
| FAG | N319-E-M1-C3 (FAG) |
