| Bore diameter | d | 60 | mm |
| Width | B | 31 | mm |
| Raceway diameter of outer ring | E | 115 | mm |
| Permissible axial displacement | s | max.2.1 |
| Outside diameter | d2 | 130 | mm |
| Shoulder diameter of inner ring | d2 | ≈84.3 | |
| chamfer dimension | rmin | min.2.1 |
| Manufacturer | Part Number |
|---|---|
| FAG | N312-E-M1 (FAG) |
