AEROQUIP FC802-08

Name: FC802-08 AEROQUIP
Brand: AEROQUIP
SKU: 819943-en-eur
Price: 47.12 EUR
Availability: SoldOut

0.41 inch x 0.79 inch x 0.79 inch

47.12 € ~~69.52 €~~ -32%

Limited stock only available on quotation

Specifications

Width	0.79 inch
Inner Diameter	0.41 inch

Outer Diameter	0.79 inch
Weight	82g

working temperature min		-40 degree fahrenheit
working pressure		500 psi
UPC		678146069467
tube material		nylon veneer
reinforcement material		polyester
product width		0.79 inch
product trade name		fc802 series
product height		0.79 inch
package weight		0.18 pound
lay line style		ink wheel
Inside diameter		0.41 inch
icc		hoses and flexible tubes
factory crimp		no
eccn		ear99
description product name		danfoss aeroquip fc802 series a/c and refrigeration hoses
cover material		epdm
conductivity		conductive
certifications		sae j51
bend radius min		3 inch
abrasion resistance		standard
hose family		refrigerant

working temperature max		250 degree fahrenheit
vacuum rating		28 inch mercury
tube wall thickness		0.38 inch
sub brand		aeroquip
qualified hose fittings		100r5 reusable-411
Product weight		0.18 pound
product length		12 inch
package form		bulk
Outside diameter		0.79 inch
language		english
impulse cycle life		150000 cycle
feature		deliver performance and maximum uptime\|hoses exceed sae j2064\|compatible with multiple refrigerants
effusion rate		hfc 134a effusion .25 lbs/ft2/yr at 176°°f (1.21 kg/m2/yr at 80°°c)
description short		a/c hose
dash size		-8
Construction		1 ply braid
Color		black
Burst pressure		2500 psi
Application		transportation, refrigeration and air conditioning systems.
product line		aeroquip
hydraulic hose		hose, refrig type d sae j51
