| Material housing | Die-cast aluminium | ||
| Note on materials | RoHS-compliant | ||
| Type of mounting | Via female thread | ||
| Reset force | 200 N | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [-:-:4] | ||
| Symbol | 00991205 | ||
| Min. installation height | 65 mm | ||
| Max. tipping angle | 15 deg | ||
| Stroke | 45 mm | ||
| Size | 80 |
| Material bellows | CR | ||
| Pneumatic connection | G1/4 | ||
| Product weight | 500 g | ||
| Ambient temperature | -40 °C ... 70 °C | ||
| Note on operating and pilot medium | Lubricated operation not possible | ||
| Operating pressure | 0 bar ... 8 bar | ||
| Mode of operation | Single-acting | ||
| Max. offset | 10 mm | ||
| Max. extended height | 110 mm | ||
| Required installation diameter | 95 mm |
