FESTO DFPI
12 Products
Discover all the available configurations for the FESTO DFPI product series Linear actuator, closed-loop control ed for process automation. Find the right product by filtering with Piston diameter [mm] and Stroke [mm].
DFPI Type Codes
| Series | Catalog Number Format | Description |
|---|---|---|
| DFPI | DFPI- - -N-D2-P-NB3 | Linear actuator, closed-loop control ed for process automation |
Typecode for Catalog Number DFPI,
DFPI- - -N-D2-P-NB3
| 001 | Series |
|---|---|
| DFPI | Linear actuator, closed-loop control ed for process automation |
| 002 | Piston diameter [mm] |
| 100 | 100 |
| 125 | 125 |
| 160 | 160 |
| 200 | 200 |
| 250 | 250 |
| 320 | 320 |
| 003 | Stroke [mm] |
| ... | 40 ... 990 |
| 004 | Cushioning |
| N | No cushioning |
| 005 | Displacement encoder |
| D2 | Analogue |
| 006 | Method of measurement |
| P | Potentiometer |
| 007 | Control unit |
| None | |
| C1 | Control er 1 |
| 008 | Regulator attachment position |
| Integrated | |
| E | External |
| 009 | Directional control valve |
| None |
| V | Integrated |
| 010 | Standard |
|---|---|
| NB3 | Based on ISO 15552 |
| 011 | Connection type |
| Standard | |
| P | Protected |
| P9 | Cable connector M16x1.5 |
| M12 | Plug M12, A-coded |
| VM12 | Prepared for expansion modules with plug M12, A-coded |
| 012 | Connection type material |
| Standard | |
| B2 | Nickel-plated brass |
| V2 | Stainless steel (austenitic chromium-nickel/1.4301, 1.4303, 1.4306 (AISI 304L)) |
| 013 | Safety position |
| Piston rod advancing | |
| R | Piston rod retracting |
| 014 | Additional function |
| Standard | |
| A | Position feedback 4 ... 20 mA |
| T | Integrated transducer 4 ... 20 mA |
| 015 | Pneumatic tubing |
| Standard | |
| M | Metal |
