PARKER D1VLB004NN4J

Name: D1VLB004NN4J PARKER
Brand: PARKER
SKU: 804384-en-eur
Price: 411.29 EUR
Availability: InStock

411.29 € ~~822.58 €~~ -50%

available with 3 to 7 days delivery to United States

Specifications

Mounting Position	unrestricted, preferably horizontal
max. pressure	350 bar
max. flow	80 l/min

Seal	nbr
Weight	1.40Kg

body material		cast iron
for fluid type		hydraulic oil according to din 51524
maximum operating temperature		60 °c
maximum operating pressure		350 bar
actuation type		manually
Mounting position		unrestricted, preferably horizontal
product series		directional control valve
spool position		3 positions, detent, operated in position a, 0 or b, no center in offset position
seal material		nbr
port connection		ng06 / cetop 03

Weight		1.4 kg
minimum operating temperature		-25 °c
maximum flow rate		80 l/min
function		3-way
operation type		direct
Mounting type		subplate mounting
spool code		4
switching option		center of rotation below spool axis
actuation		hand lever side a
