PARKER D02B2-0,2V

Name: D02B2-0,2V PARKER
Brand: PARKER
SKU: 802553-en-eur
Price: 22.02 EUR
Availability: SoldOut

22.02 € ~~44.04 €~~ -50%

Limited stock only available on quotation

Specifications

max. pressure	6000 psi, 420 bar
max. flow	21 gal/min, 80 l/min

Seal	fluorocarbon
Weight	50g

Weight		0.11 lb, 0.05 kg
maximum operating temperature		+400 °f, +204 °c
installation torque		30 lb-ft, 40 nm
valve material		all parts steel. all operating parts hardened steel
maximum kinematic viscosity		45-2000 ssu (6 to 420 cst)
Flow direction		2-1 checked, 1-2 free flow
function		standard check
maximum inlet pressure rating		6000 psi, 420 bar
flow rate		12 @ 100 psi (7 bar) nominal gal/min, 45 @ 100 psi (7 bar) nominal l/min
seal material		fluorocarbon
maximum flow rate		21 gal/min, 80 l/min

minimum operating temperature		-15 °f, -26 °c
Operating temperature		-15 to +400 °f, -26 to +204 °c
cavity size		c08-2
filter efficiency rating		iso 4406 18/16/13, sae class 4
for fluid type		mineral-based or synthetic hydraulic fluids
actuation type		pressure sensing
leak rate		< 3 @ 6000 psi (420 bar) drops/min
maximum operating pressure		6000 psi, 420 bar
division		mobile systems division europe
cracking pressure		3 psi, 0.2 bar
