| repairable | yes | ||
| body type | square | ||
| body material | zinc plated steel | ||
| specifications met | - | ||
| position sensing type | - | ||
| maximum operating pressure | 8 bar, 116 psi | ||
| Port size | g1/4 | ||
| retract stroke force | 3000 n, - | ||
| maximum stroke length | 40 mm, 1.9 inch | ||
| cylinder type | non-guided |
| corrosion resistance included | no | ||
| end cap material | zinc plated steel | ||
| piston rod material | steel | ||
| mounting option | direct | piston rod | ||
| Operating temperature | -20 to +70 °c, -4 to +158 °f | ||
| rod end thread type | male | ||
| cushioning type | - | ||
| extend stroke force | 3000 n, - | ||
| bore diameter | 80mm | ||
| cylinder action | double acting |
