PARKER BVG4P-1/2 LOCK

Name: BVG4P-1/2 LOCK PARKER
Brand: PARKER
SKU: 561082-en-eur
Price: 46.79 EUR
Availability: InStock

46.79 € (vat. excl.)

5 pcs. with 1 to 3 days delivery to France

Specifications

BVGL & BVGLOCK series ball valves feature a nickel plated brass body and a chrome plated brass ball and are manufactured with long female threads.

max. pressure	14 bar, 1.4 mpa, 203 psi
Seal	ptfe

Weight	239g

o-ring material		fpm
stem seal material		fpm, double o'ring
stem material		nickel plated brass
diameter nominal (dn)		15
shape		in-line
Brand		legris
industry		industrial manufacturing equipment
technology		fluid & gas handling, process control, pneumatics
product style		vented lockable female ball valve
function		2-way
maximum operating pressure		14 bar, 1.4 mpa, 203 psi
connection size		g1/2
configuration		2/2
minimum operating temperature		-10 °c, 14 °f
Mounting type		in-line
specifications met		di: 97/23/ec (module ped a - diameters greater than 25 mm), di: 2006/42/ec (machinery directive), rohs, reach
seal material		ptfe
handle type		black long lever (treated steel)
quantity per box		20

handle		lockable lever, treated steel
connection 1 thread size (metric)		g1/2
ball seal material		ptfe
body material		nickel plated brass
Operating pressure		0 to 1.4 mpa, 0 to 40 bar
division		low pressure connectors europe division
Application		pneumatics, process control, safety, fluid control, agricultural machinery, textile, plumbing, air conditioning, heating
product type		ball valves
product series		standard series
operation type		lever-operated
connection type		bspp
orifice size		15 mm
for fluid type		gas, water, water vapour, oil, all fluids compatible with the component materials
maximum operating temperature		100 °c, 212 °f
actuation type		manual
seat material		ptfe
ball material		nickel plated brass
Weight		0.239 kg, 0.5258 lb
region of origin		italy
