| material guide rods | hardened heat-treated steel | ||
| carrying plate | aluminum | ||
| bearing housings | aluminum | ||
| weight 0 mm stroke | 2.3 kg | ||
| min. ambient temperature | -20 °c | ||
| Stroke | 200 mm |
| material flexible coupling in carrying plate | stainless steel | ||
| Bearing Type | sintered bronze | ||
| weight +10 mm stroke | 0.016 kg | ||
| max. ambient temperature | 80 °c | ||
| for standard cylinders | iso 15552 | ||
| piston Ø | 40 mm |
