81124-TV INA

INA
Bearings
Roller Bearings
Roller Thrust Bearings
81124-TV

INA 81124-TV

0000564640000

120mm x 155mm x 25mm

258.28 € (vat. excl.) ~~393.74 €~~ -34%

50+ pcs. with 1 to 3 days delivery to France

Specifications

Width	25mm
Inner Diameter	120mm

Outer Diameter	155mm
Weight	1.05Kg

Dimensions

Main Dimensions & Performance Data

Bore diameter	d	120	mm
Height	T	25	mm
Basic static load rating, axial	C_0a	760,000
Limiting speed	n_G	2,090

Outside diameter	D	155	mm
Basic dynamic load rating, axial	C_a	214,000
Fatigue load limit, axial	C_ua	67,000
Reference speed	n_ϑr	780	1/min

Mounting dimensions

Minimum diameter shaft shoulder	d_{a min}	151	mm
Maximum recess radius	r_{a max}	1	mm

Maximum diameter of housing shoulder	D_{a max}	124	mm

Dimensions

Rip diameter shaft washer	d₁	155	mm

Minimum chamfer dimension	r_min	1	mm

Related products

4T-HM903245/HM903210

NTN

66.93 €

GH195-32

AEROQUIP

296.29 €

EC881-12

AEROQUIP

23.02 €

EC810-20

AEROQUIP

167.92 €

GH506-24

AEROQUIP

105.42 €

4T-HM804849/HM804810

NTN

79.44 €

51124

SNR

195.87 €

4T-3776/3720

NTN

43.02 €

51124.C15

FAG

113.49 €

51124

NSK

97.88 €

4T-53177/53375

NTN

102.97 €

81124 T2

NTN

188.42 €

51124

SKF

217.21 €

51124

ZEN

42.91 €

GH466-20

AEROQUIP

121.60 €

GH781-32

AEROQUIP

98.70 €

258.28 € (vat. excl.)

Stock	50+ pcs.
Part number	81124-TV
Manufacturer	INA

Quantity	Unit Price
1 - 4	258.28 €
5 - 9	253.11 €
10 - 14	247.95 €
15+	242.78 €
