PARKER 80CN110QBM3KR321

Name: 80CN110QBM3KR321 PARKER
Brand: PARKER
SKU: 761989-en-eur
Price: 2607.87 EUR
Availability: InStock

2,607.87 €

2 pcs. with 1 to 3 days delivery to United States

Specifications

max. flow	520 l/min (140 gal/min)
Seal	nitrile

Weight	0g

flow rate		520 l/min (140 gal/min)
seal material		nitrile
bypass valve pressure rating		3.5 bar (50 psi)
micron rating		10 µm
indicator pressure setting		2.5 bar
pressure rating		1000 psi (69 bar)
Housing Material		aluminum
maximum operating temperature		225 f (107 c)
compatible element		see tech specifications tab after model selected for replacement element part number.
product type		hydraulic filter

filter element type		10q microglass
port connection type		sae flange 2" 3000-m
Options		no drain
indicator type		visual automatic reset
mounting style		inline
port type		sae-12 straight threads, 3/4” npt, sae-16 straight threads, 1” npt, 1-1/2” npt, sae-24 straight threads, flange face, sae 2”, code 6, 2” npt, sae-32 straight threads
for fluid type		suitable for use with mineral and vegetable oils, and some syntetic oils. for other fluids, please e-mail technical support at hff.technical@support.parker.com or call 800-253-1258.
Weight		see tech specifications tab after model selected for weight
product style		hydraulic filter
