| max. particle size | 50 µm | ||
| min. medium temperature | -20 °c | ||
| stroke max. | 2600 mm | ||
| weight 0 mm stroke | 4.2 kg | ||
| ports | g 1/2 | ||
| working pressure min. | 2 bar | ||
| min. ambient temperature | -20 °c | ||
| retracting piston force | 4503 n | ||
| scraper | standard industrial scraper | ||
| environmental requirements | industry standard | ||
| Cushioning | pneumatic adjustable cushioning | ||
| Stroke | 75 mm | ||
| Standards | cnomo / nfe 49-001 |
| max. medium temperature | 80 °c | ||
| Medium | compressed air | ||
| weight +10 mm stroke | 0.183 kg | ||
| Piston rod thread | m27x2 | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 80 °c | ||
| extracting piston force | 4948 n | ||
| pressure for determining piston forces | 6,3 bar | ||
| piston rod | single | ||
| magnetic piston | piston with magnet | ||
| functional principle | double-acting | ||
| piston Ø | 100 mm |
