| Bore diameter | d | 80 | mm |
| Width | B | 39 | mm |
| Shoulder diameter inner ring (small side face) | d2 | ≈97.07 | |
| Distance pressure point | a | 72 | mm |
| Chamfer dimension outer ring small side face | r3,4 | min.1.1 |
| Outside diameter | d2 | 170 | mm |
| Shoulder diameter inner ring (large side face) | d1 | ≈115.2 | |
| Shoulder diameter outer ring (large side face) | D1 | ≈136.75 | |
| chamfer dimension | rmin | min.2.1 |
| Manufacturer | Part Number |
|---|---|
| FAG | 7316-B-XL-TVP-UO (FAG) |
