| nominal input value | 4 ... 20 ma | ||
| signal connection | en 175301-803, form a | ||
| Protection class | ip54 | ||
| permissible ripple | 5% | ||
| Hysteresis | 0,04 bar | ||
| control | analog | ||
| Medium | compressed air | ||
| compressed air connection output | g 1/4 | ||
| max. ambient temperature | 50 °c | ||
| working pressure max | 11 bar | ||
| certificates | ce declaration of conformity |
| actual output value | 4 ... 20 ma | ||
| Electrical connection | en 175301-803, form a | ||
| max. power consumption | 200 ma | ||
| mounting orientation | vertical | ||
| dc operating voltage | 24 v | ||
| nominal flow qn | 800 l/min | ||
| compressed air connection, exhaust | g 1/4 | ||
| compressed air connection input | g 1/4 | ||
| min. ambient temperature | 5 °c | ||
| working pressure min. | 0.5 bar | ||
| Type | poppet valve |
