| Bore diameter | d | 150 | mm |
| Total bearing width | T | 49 | mm |
| Width Inner ring | B | 45 | mm |
| Corner radius inner ring | r1,2 | min.4 | |
| Distance pressure point | a | 50.38 | mm |
| Outside diameter | d2 | 270 | mm |
| Inner ring shoulder diameter | d1 | ≈200.13 | |
| Width Outer ring | C | 38 | mm |
| Corner radius outer ring | r3,4 | min.3 |
| Manufacturer | Part Number |
|---|---|
| FAG | 30230-A (FAG) |
