| r1a - Max fillet radius | 2 mm | ||
| Cb - Min clearance | 8 mm | ||
| Db min - Min OR shoulder diameter | 168 mm | ||
| Da min - Min shoulder diameter OR | 157 mm | ||
| da max - Max shoulder diameter IR | 116 mm | ||
| FTF - Characteristic cage frequency | 0,429 Hz | ||
| BPFO - Characteristic outer ring frequency | 8,576 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nlim - Oil lubrication limit speed | 2700 tr/min | ||
| Y0 - Static axial load coefficient | 0.79 | ||
| A2 - Rating life coefficient | 1 | ||
| C0 - Static load | 335 kN | ||
| ISO 355 reference | T3FB100 | ||
| rs - Min fillet radius | 3 mm | ||
| T - Total width | 37 mm | ||
| Brand | NTN |
| ra max - Max fillet radius | 2,5 mm | ||
| Ca - Min clearance | 5 mm | ||
| Da max - Max shoulder diameter OR | 168 mm | ||
| db min - Min IR shoulder diameter | 114 mm | ||
| BSF - Characteristic rolling element frequency | 6,626 Hz | ||
| BPFI - Characteristic inner ring frequency | 11,424 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Grease lubrication limit speed | 2000 tr/min | ||
| Y2 - Upper axial load coefficient | 1.43 | ||
| e - Coefficient | 0.42 | ||
| Cu - Fatigue limit load | 37 kN | ||
| C - Dynamic load | 286 kN | ||
| r1s - Min fillet radius | 2,5 mm | ||
| a - Charge load application point | 36 mm | ||
| C - Outer ring width | 29 mm |
