| type label customer data | none | ||
| protection type ip (max. with suitable connector) | ip65/67 | ||
| Protocol | service-büs | ||
| electrical connection 1 type | mp multipol | ||
| opening time typical | 3.400 ms | ||
| return type | electrical, energy storage | ||
| product sub-group | process control valve | ||
| control cone variant | equal percentage 50 : 1 | ||
| function | positioner | ||
| Cv value | 1,45 gal/min | ||
| interface to actuator | nipple thread m28 x 1,5 (standard dn 13,15) | ||
| actuator material 2 | pps (polyphenylene sulphide) | ||
| approval type | material-approval-foods | ||
| seat seal material | stainless steel | ||
| temperature medium max | 185 °c | ||
| nominal pressure (din en 1759) | class 150 | ||
| nominal pressure max | 25 bar | ||
| valve body internal surface | without processing | ||
| port connection 1 standard | din en iso 1127 / iso 4200 / din 11866 series b | ||
| port connection 1 dn | dn 15 (nps 1/2) - 21,3x1,6 | ||
| fluidic port connection number | 2 |
| protection type nema (max. with suitable connector) | nema 4x | ||
| control interface | no display - internal buttons | ||
| control unit | analogue | ||
| closing time typical | 3.400 ms | ||
| main valve operating principle | globe valve | ||
| flow | below seat | ||
| Type | 3,361 | ||
| auxiliary function | sim card | ||
| seat size | 6 mm (1/4") | ||
| kv value (water) | 1,25 m3/h | ||
| driving force electromotor | ag2 (1300 n) | ||
| actuator material | aluminium powder-coated | ||
| packed seal enclosed | yes | ||
| temperature environment min | -25 °c | ||
| temperature medium min | -10 °c | ||
| nominal pressure (din en 1333) | pn 25 | ||
| nominal pressure min | 0 bar | ||
| valve body material | stainless steel | ||
| port connection 1 type | welded | ||
| manual actuation | yes | ||
| Customscode | 84818059 |
