1100P08 02 Parker Hannifin

PARKER 1100P08 02

Name: 1100P08 02 PARKER
Brand: PARKER
SKU: 581392-en-eur
Price: 128.26 EUR
Availability: InStock

128.26 € /m ~~256.52 €~~ /m -50%

available with 3 to 7 days delivery to United States

Specifications

Tried-and-tested for industrial or vehicle applications, PA tubing guarantees excellent durability due to its stable long-term mechanical properties.
Special grade of semi-rigid polyamide manufactured according to our Eco-Design approach.

max. pressure	50 bar

Weight	2.70Kg

Technical data

tube o.d. (mm)		8
tube i.d. (mm)		6
Length (m)		100
maximum operating pressure		50 bar
maximum operating temperature		up to 100°c - see the graph “working pressure/working temperature”
Weight		2.7 kg/package
number of tubes		1
media		semi-rigid pa: compressed air, other fluids /rigid pa: compressed air,lubricants, other fluids

tubing material		pa
Color		green
weight (per unit of measure)		0.023 kg/m
minimum operating temperature		-40 °c
vacuum pressure rating		755 mm-hg
bend radius		35 mm
Application		packaging, tooling, compressed air, motion technologies, robotics, industrial machinery
specifications met		industrial: di: 2002/95/ec (rohs), 2011/65/ec; di: 97/23/ec (ped); rg: 1907/2006 (reach)/transportation: chemical performance and resistance tested according to din 74324 -1 / din 73378 / iso 7715
