AVENTICS 0820401005

Name: 0820401005 AVENTICS
Brand: AVENTICS
SKU: 379577-en-eur
Price: 187.97 EUR
Availability: InStock

VVAP-4/2DM-LEV

187.97 €

2 pcs. with 1 to 3 days delivery to United States

Specifications

max. pressure	10 bar
Seal	acrylonitrile butadiene rubber

Weight	530g

activation		mechanical
compressed air connection output		g 1/4
working pressure max		10 bar
Type		poppet valve
min. ambient temperature		-30 °c
min. medium temperature		-30 °c
Medium		compressed air
oil content of compressed air max.		5 mg/m³
compressed air connection type		internal thread
compressed air connection, exhaust		g 1/4
Housing Material		aluminum
material actuating control		polyamide, steel

nominal flow qn		550 l/min
working pressure min.		0 bar
actuating element		lever
plate connection		pipe connection
max. ambient temperature		80 °c
max. medium temperature		80 °c
oil content of compressed air min.		0 mg/m³
max. particle size		5 µm
compressed air connection input		g 1/4
Weight		0.53 kg
seal material		acrylonitrile butadiene rubber
