| Housing Material | polyphenylene sulfide, polyamide fiber-glass reinforced | ||
| max. ambient temperature | 50 °c | ||
| Duty cycle | 100 % | ||
| protection class with connection | ip65 | ||
| electrical connection type | plug | ||
| working pressure max | 10 bar | ||
| nominal flow qn | 25 l/min | ||
| Valve function | nc | ||
| frame size | do16 |
| Weight | 0.035 kg | ||
| min. ambient temperature | -10 °c | ||
| Sealing principle | soft seal | ||
| electrical connection size | iso 15217, form c | ||
| operational↩voltage | 110 v ac | ||
| working pressure min. | 0 bar | ||
| Manual override | without detent | ||
| switching principle | 3/2, with spring return | ||
| activation | electrically |
