0439 07 13 Parker Hannifin

PARKER 0439 07 13

Name: 0439 07 13 PARKER
Brand: PARKER
SKU: 549771-en-eur
Price: 63.18 EUR
Availability: InStock

63.18 € ~~126.36 €~~ -50%

available with 7 to 15 days delivery to United States

Specifications

This range of valves has patented seal wear compensating technology for reliable and durable sealing, protecting any system whether under pressure or vacuum.

max. pressure	vacuum to 40 bar, vacuum to 580.16 psi, vacuum to 4 mpa
max. flow	n/a l/min

Seal	nbr
Weight	480g

Technical data

connection 1 thread size (metric)		g1/4
diameter nominal (dn)		7
shape		in-line
minimum operating temperature		up to -40 °c/°f without movement of the handle, -4 °f, -20 °c
division		low pressure connectors europe division
Application		pneumatics, process control, safety, fluid control
product style		vented lockable female ball valve
function		3-way
maximum operating pressure		vacuum to 40 bar, vacuum to 580.16 psi, vacuum to 4 mpa
flow rate		n/a l/min
connection size		g1/4
configuration		3/2
maximum operating temperature		80 °c
actuation type		manual
body material		nickel plated brass
seal material		nbr
o-ring material		nbr
Weight		0.480 kg, 1.058 lb
region of origin		france
ball seal material		nbr

connection 1 thread style		bspp
handle		zamak
product type		ball valves
Brand		legris
industry		industrial manufacturing equipment
technology		fluid & gas handling, process control, pneumatics
product series		universal series
operation type		lever-operated
maximum flow rate		n/a l/min
connection type		bspp
orifice size		7 mm
for fluid type		air, inert gas, water
Mounting type		in-line
specifications met		di: 97/23/ec (module ped a - diameters greater than 25 mm), di: 2006/42/ec (machinery directive), rohs, reach
seat material		rilsan graphited
stem material		brass
handle type		red long lever (zamak)
quantity per box		2
stem seal material		nbr
