| Adapter sleeve reference | H2313 | ||
| Operating temperature min. | -20 °C | ||
| C - Dynamic load rating | 57,2 kN | ||
| N - Mounting hole dimension | 19 mm | ||
| J - Mounting holes distance | 170 mm | ||
| G - Grease fitting | M6x1 | ||
| Dz - Outer diameter of cover | 132 mm | ||
| B1 - Overall width IR (with eccent. locking collar/adapt. sleeve) | 65 mm | ||
| A2 - Total height from mounting surface | 48 mm | ||
| A - Housing height | 49 mm |
| Operating temperature max. | 100 °C | ||
| C0 - Static load rating | 40 kN | ||
| Z - Width over covers | 74,9 mm | ||
| L - Housing width / diameter | 205 mm | ||
| H3 - Centering dia | 145 mm | ||
| e - Distance mounting surface to bearing center | 16 mm | ||
| d1 - Outer dia of eccent. Lock. collar / nut of adapter sleeve | 85 mm | ||
| A4 - Housing height from mounting surface | 35 mm | ||
| A1 - Housing foot height / flange height | 15 mm | ||
| Brand | SNR |
