| Inner Ring Width B | 38.10 | mm | |
| Bolt Hole Length N1 | 21 | mm | |
| Foot Height H1 | 13 | mm | |
| Dimension L1 | 43.50 | mm | |
| Total Height H2 | 81 | mm | |
| Housing Width A | 36 | mm |
| Center of Bearing from End S | 15.90 | mm | |
| Bolt Hole Size N | 17 | mm | |
| Base to Center Height H | 42.90 | mm | |
| Bolt Hole Spacing J | 121 | mm | |
| Total Length L | 165 | mm |
| Bearing Style | Ball Bearing | ||
| Locking Style | Set Screw Locking | ||
| Lubrication Type | Food Grade Solid Lube | ||
| Bearing Number | SUC206/FVSL613 |
| Housing Construction | Two-Bolt Pillow Block | ||
| Weight | 1.30 | Kg | |
| Bore Size | 30 | mm | |
| Housing Material | Cast Stainless Steel |
