| material front cover | aluminum | ||
| max. particle size | 5 µm | ||
| max. medium temperature | 60 °c | ||
| max. ambient temperature | 60 °c | ||
| working pressure max | 8 bar | ||
| stroke max. | 3700 mm | ||
| Cushioning | adjustable | ||
| Cushioning length | 20 mm | ||
| piston force | 507 n | ||
| Guide | ball rail guide | ||
| functional principle | double-acting | ||
| Stroke | 100 mm |
| Weight | 7.5 kg | ||
| Medium | compressed air | ||
| min. medium temperature | -10 °c | ||
| min. ambient temperature | -10 °c | ||
| working pressure min. | 3 bar | ||
| speed max. | 2 m/s | ||
| cushioning energy | 7 j | ||
| pressure for determining piston forces | 6,3 bar | ||
| easy2combine | capable with connection kit | ||
| magnetic piston | with magnetic piston | ||
| ports | g 1/8 | ||
| piston Ø | 32 mm |
