| activation | electrically | ||
| working pressure min. | 3 bar | ||
| dc operating voltage | 24 v | ||
| Manual override | without detent | ||
| return | with spring/air spring return | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| max. particle size | 40 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| compressed air connection, exhaust | Ø 8 | ||
| Duty cycle | 100 % | ||
| Housing Material | polyamide, polyoxymethylene |
| compressed air connection output | base plate | ||
| working pressure max | 8 bar | ||
| voltage tolerance dc | -15% / +10% | ||
| actuating control | single solenoid | ||
| min. ambient temperature | 5 °c | ||
| min. medium temperature | 5 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| compressed air connection input | Ø 8 | ||
| power consumption dc | 2 w | ||
| protection class with connection | ip65 |
