| Note on materials | RoHS-compliant | ||
| Interface code, actuator | V20 | ||
| Transmittable torque | 0,05 Nm | ||
| Mass moment of inertia | 2,11 kgmm² | ||
| Degree of protection | IP40 | ||
| Storage temperature | -20 °C ... 60 °C | ||
| Max. rotational speed | 3.000 rpm | ||
| Mounting position | optional | ||
| Size | 30 |
| Interface code, motor in | 28A | ||
| Product weight | 97 g | ||
| Frictional torque independent of load | 0,015 Nm | ||
| Ambient temperature | 0 °C ... 50 °C | ||
| Relative air humidity | 0 - 95% | ||
| LABS (PWIS) conformity | VDMA24364 zone III | ||
| Gear unit ratio | 1:1 | ||
| Centre-to-centre distance | 44 mm |
