| Medium | compressed air | ||
| min. medium temperature | -10 °c | ||
| min. ambient temperature | -10 °c | ||
| control pressure min. | 2 bar | ||
| connection type | pipe connection | ||
| pilot valve width | 15 mm | ||
| Sealing principle | metal/metal sealing | ||
| electrical connection size | iso 15217, form c | ||
| Manual override | without detent | ||
| operational voltage ac at 50 hz | 230 v | ||
| working pressure min. | 2 bar | ||
| switching principle | 5/2 | ||
| activation | electrically |
| max. medium temperature | 50 °c | ||
| max. ambient temperature | 50 °c | ||
| control pressure max. | 10 bar | ||
| return | with spring return | ||
| valve type | spool valve | ||
| pilot | internal | ||
| actuating control | single solenoid | ||
| electrical connection type | plug | ||
| voltage tolerance ac 50 hz | -10% / +10% | ||
| working pressure max | 10 bar | ||
| compressed air connection output | g 1/8 | ||
| nominal flow qn | 280 l/min |
