| industrial valves | dg4v-3-2a-m-ftwl-d7-hl7- 60 | ||
| valve type | dg4v : (dg4v) sol. operated sub plate mounted dcv, 350 bar at ports a, b & p | ||
| performance | (0) high performance | ||
| spring arrangement | a : (a) spring offset, end to end. single end. | ||
| Manual override | (0) plain override in solenoid ends only | ||
| spool monitoring switch | (0) no spool position monitoring switch | ||
| solenoid indicator light | l : (l) solenoid indicator light | ||
| coil voltage | -hl : (hl) 24v dc 18 watt | ||
| design code | -60 : (60) design number |
| Seal Type | (0) viton | ||
| interface | -3 : (3) iso/din 4401-ab-03, size 3 interface | ||
| spool type | -2 : (2) p,a,b,t blocked | ||
| build orientation | (0) standard build | ||
| solenoid identification | -m : (m) flag with standard build as per ansi b93 9 | ||
| coil type | -ftw : (ftw) fly. lead wired terminal block & 1/2" npt thread wiring housing | ||
| diode | -d7 : (d7) encapsulated diode, transzorb type | ||
| tank port rating | 7 : (7) 210 bar (3000 psi) for dc high performance models |
