| Maximum Inlet Pressure (psi) | 5,000 | ||
| Seal Material | Nitrile | ||
| Type/Configuration | Normally Closed | ||
| Rated Flow (gpm) | 50 | ||
| Flow Rate | 50 Gal/min, 190 L/min | ||
| Configuration | Normally Closed | ||
| Cavity Size | C16-2 | ||
| Wire Mesh Screen Included | N/A | ||
| Maximum Kinematic Viscosity | Mineral-based or synthetic with lubricating properties at viscosities of 45-2000 SSU (6 to 420 cSt) cSt | ||
| Weight | 0.88 lb, 0.4 kg | ||
| Coil Nut Tightening Torque | 3 lb-ft, 4.4 Nm |
| Override | N/A | ||
| Response Time (ms) | 50 | ||
| Wire Screen | N/A | ||
| Flow Direction | Bi-directional | ||
| Maximum Inlet Pressure Rating | 5000 psi, 350 bar | ||
| Leak Rate | 9 drops/min | ||
| Response Time | 50 ms | ||
| Valve Material | All parts steel. All operating parts hardened steel | ||
| Filter Efficiency Rating | ISO 4406:1999 Code 18/16/13 | ||
| Installation Torque | 80 lb-ft, 108 Nm | ||
| Coil Type | 1/2" Super Coil High Watt (P) |
